Heatless Air Dryers

APPLICATION

  • CNC & CMM machining
  • Spray painting & powder coating
  • Nitrogen generation & laboratory gas
  • Instrumentation & process-air systems

Features

  • 100 % rust-free aluminum construction
  • Compact footprint with easy installation
  • Fully automatic tower sequencing
  • ISO 8573-1 Class 2 air quality
  • Energy-efficient purge cycle, minimal maintenance
  • No external heat or coolant required

Inquiry form

Please enable JavaScript in your browser to complete this form.
Name
Category:

Description

Heatless Air Dryers

International-standard manufacturer of Heatless Compressed Air Dryers. Our Heatless Air Dryers deliver ultra-dry, moisture-free air for critical applications—without using external heaters—by harnessing advanced adsorption technology.

Working Principle

Compressed air is first cleaned by a coalescing pre-filter, then directed into one of two desiccant-filled towers where moisture is adsorbed. After a timed cycle, 10–12 % of the dried air purges and regenerates the saturated tower while the alternate tower continues adsorption. Automatic sequencing guarantees a continuous supply of stable, moisture-free air at the set dew point.

Key Specifications

Working Pressure: 4–12 bar (up to 16 bar optional)
Temperature Range: 5–45 °C
Pre-filter Rating: 0.1 μm coalescing
Built-in Post-filters: 2 × 20 μm
Purge Air Consumption: 10–12 %
Dew Point: –40°C / 60°C standard ADP
Voltage: 230 V, 1 Ph, 50 Hz
